LS20 Inductive Proximity Sensor AC/DC IP67
LS20 inductive proximity sensor with 10mm sensing distance, AC/DC compatible, IP67 rated for industrial automation applications.
Contact Us for Pricing
Interested in this product? Contact us now for detailed pricing and product information.
Product Details
Overview
The LS20 inductive proximity sensor is a cost-effective detection solution with a plastic housing, offering reliable performance for general industrial use.
Key Features
- Dual power supply: 10–30VDC / 90–250VAC
- Sensing distance: 10mm (non-flush mount)
- Output options: PNP/NPN, NO/NC/NO+NC
- Maximum output current: ≤200mA, low power consumption <15mA
- Response frequency: 300Hz (DC) / 10Hz (AC)
- Operating temperature: -25°C to +70°C
- IP67 protection class for reliable operation in harsh environments
LS20 vs LS18: Quick Comparison
| Item | LS18 | LS20 |
|---|---|---|
| Product Model | LS18 | LS20 |
| Supply Voltage | 10…30VDC / 90…250VAC | 10…30VDC / 90…250VAC |
| Switch Output | PNP / NPN / Analog | PNP / NPN |
| Output Status | NO / NC / NO+NC | NO / NC / NO+NC |
| Sensing Distance | 5 / 8 mm | 10 mm |
| Output Current | ≤200 mA | ≤200 mA |
| Output Voltage Drop | DC＜4V, AC＜10V | DC＜4V, AC＜10V |
| Consumption Current | ＜15 mA | ＜15 mA |
| Repeat Accuracy | ＜3% | ＜3% |
| Response Frequency | 500 Hz / 20 Hz | 300 Hz / 10 Hz |
| Operating Temperature | －25℃ ~ +70℃ | －25℃ ~ +70℃ |
| Insulation Resistance | ≥50 MΩ | ≥50 MΩ |
| Housing Material | Metal | Plastic |
| Protection Grade (Compliant with IEC529 and EN60529 standards) | IP67 | IP67 |
| Mounting Type | Flush / Non-flush Mount | Non-flush Mount |
| Wiring Method | Cable / Connector | Cable / Connector |
| Compliance Standard | GB/T14048.10-2016 / IEC60947-5-2:2012 | GB/T14048.10-2016 / IEC60947-5-2:2012 |
Choose LS18 for metal housing, flush mounting, and analog output. Choose LS20 for longer sensing distance and cost-effective plastic housing.
Applications
Suitable for material handling equipment, assembly lines, and various industrial control systems.
Customization
Contact us for custom wiring options, output types, and special mounting requirements.
